TT Electronics FlexSense optical encoder sensors feature on-the-fly, long term programmability
FlexSense
Woking, UK, 26 January 2022 – TT Electronics, a global provider of engineered electronics for performance critical applications, announced the launch of FlexSense, a technology designed to optimise optical encoder applications.
The FlexSense series consists of the FS210 Transmissive Incremental Encoder and the FS310 Reflective Incremental Encoder Sensors. Highlighting the depth of TT’s engineering expertise, the FlexSense encoder sensor array vastly reduces the design complexities of optical encoder solutions.
“Low-cost control electronics are trending up. At the same time, demand for customised high-end optical encoder sensors is also growing. We saw an opportunity to address both developments in tandem,” says Walter Brooks, global product manager Optoelectronics, TT Electronics. “FlexSense is the result, a flexible solution that can be configured quickly to meet optical encoder design requirements including higher resolution, faster response, a smaller footprint, and greater intelligence. With FlexSense, TT customers can accelerate time-to-market, reduce solution complexity, and increase manufacturing throughput now and in the future.”
The FlexSense sensor integrates several key features including auto-alignment capability, a closed-loop LED driver, on-chip diagnostics, and a state-of-the-art 8x interpolator. In addition, the fully programmable array system on chip (SOC) provides a versatile solution that can adapt to a multiple range of code-disk diameters and pulses per revolution, as well as several LEDs available in the market, including TT’s OP207CL encoder LED. If the encoder code-disk is later altered, FlexSense can be reprogrammed to meet changing requirements extending the sensor’s value-add to suit future designs and negating the cost of purchasing a different sensor.
For deeper insight on the FS210 and FS310 performance specifications, click here to access the datasheet and for additional detail on the evaluation kit, visit here.
